380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle

380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle

  • 380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle
380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle
Product Details:
Place of Origin: China
Brand Name: MERROCK
Certification: CE
Model Number: S12-750
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: USD3500/PC
Packaging Details: Export Carton & Iron Frame
Delivery Time: 5-10 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 500pcs/month
Contact Now
Detailed Product Description
Product Name: Marble Floor Polisher Function: Concrete, Terrazzo, Marble Polishing
Grinding Head: 12 Heads Motor: 20HP
Inverter: 20HP Rotating Speed: 0-1500rpm
Certificates: CE, ISO Weight: 510KG
High Light:

Adjustable Handle Marble Floor Polisher

,

750MM 12 Heads Marble Floor Polisher

,

380V Marble Floor Grinding Machine

380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle



MERROCK Profile.pdf

Feature:



1. Aluminum die-casting gear box

2. Global well-known brands motor and inverter

3. External vacuum port

4. Components through precision lathe processing

5. With emergency stop button and reverse button on panel

6. Multifunctional grinding discs can be fixed various polishing pads to reduce the cost












380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle 0



380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle 1





380V 750MM 12 Heads Marble Floor Polisher With Adjustable Handle 2



Parameters:



Item Data
Model S12-750
Voltage 380V
Motor 20HP
Inverter 20HP
Speed 0-1500rpm
Work width 750*750mm2
Water tank 30L
Grinding heads 12pcs
Grinding disc 4pcs
Weight 510





Application & Function:



  • Used for old expoxy curing, stone grinding, old ground refurbishment, high-speed rails, etc.
  • It is highly efficient and has excellent results.
  • Multifunctional grinding discs can be installed with various types of grinding consumables to minimize your construction cost.
  • The product occupy rarely space with foldable handle.
  • Multifunctional magnetic grinding plate.

Diamond Polishing Pads With Different Grits

Seven particle size numbers of diamond polishing pads which are 50#, 100#, 200#, 400#, 800#, 1500#, 3000# are conventional polishing pads in the stone processing industry, also called the basic particle size. Because the manufacturing technology of this polishing pad is mature and the effect is reliable. In fact, the new type of three-step or five-step polishing pads are not as good as this conventional polishing pads in terms of optimization effect. From 50#~3000#, the scratch can be optimized very well. This type of polishing pad has very clear polishing steps and polishing effect.

1. 50-400# diamond polishing pads

Diamond polishing pads of these particle sizes are all using abrasive particles to cut away minerals on the surface of the stone, and the grinding effect is dominant. It is used for leveling during grinding. Relying on rough abrasives, the height difference can be quickly flattened and ready for the next stage.

2. 800# diamond polishing pads

This type of diamond polishing pad is quite special. It is the preparatory polishing stage. It serves as a link between the previous and the next, giving a finishing to the front grinding process and a beginning to the back filling process. So it is a complex of "grinding effect & filling effect". The two functions exist at the same time.

3. 1500-3000# diamond polishing pads

Diamond polishing pads of these particle sizes are mainly based on the release of resin in the polishing pads for filling process to form high gloss. The filling effect is dominant, and the grinding effect is still there, but it is very weak. The abrasive of polishing pads is very delicate, and the filling effect of the resin is strengthened to grind the stone out of high gloss.
